Velika bimetalna čahura s navojem

Structure and Materials

Vanjski dio ima kućište od ugljičnog čelika ili legiranog čelika visoke čvrstoće, čime se osigurava cjelovitost strukture i otpornost na udarce.

The internal lining consists of a highly wear-resistant copper alloy (high-strength brass), offering both superior wear resistance and self-lubricating properties.

Unutarnji provrt strojno je izrađen s preciznim trapezoidnim ili potpornim navojem koji se spajaju s glavnim vijkom za prijenos opterećenja velike tonaže.

Ključne značajke

Side-positioned holes serve as lubrication ports or oil grooves, facilitating lubrication and heat dissipation under high-pressure operating conditions.

Rupe za vijke na licu prirubnice koriste se za montažu i osiguranje opreme, osiguravajući preciznost montaže i koaksijalnost.

I unutarnje i vanjske površine podvrgnute su visokopreciznom tokarenju i brušenju kako bi se zajamčila točnost pristajanja i kvaliteta zahvaćanja navoja.

Application Scenarios

Primarily used in heavy-duty equipment such as large hydraulic presses, screw presses, and forging presses, serving as a critical nut component in the main drive system, it withstands high loads and frequent reciprocating motion and friction while ensuring operational stability and precision.
